Standard expansion joints are not always sufficient for demanding piping systems. High pressure, large thermal movements, limited installation space, severe operating conditions, or special process requirements often require custom-engineered solutions.
KLINGER Turkey designs and manufactures Special Expansion Joints specifically engineered according to project requirements rather than standard catalog dimensions. Each expansion joint is developed through engineering calculations considering operating pressure, temperature, movement requirements, piping loads, installation conditions, fatigue life, and applicable international standards such as EJMA, ASME, EN 14917, and customer specifications.
From concept design to final manufacturing, every unit is optimized to provide reliable operation, long service life, and safe system performance.
KLINGER Turkey works closely with EPC contractors, engineering companies, OEMs, and end users to develop tailor-made expansion joint solutions for the most demanding industrial applications.
Diameter
DN25-DN8000
Design Pressure
-1/+ 130 barg
Design Temperature
-196 / +1200 °C
Materials
904L, Inconel 600/625/800H/825, 254 SMO, Duplex 2205/2507, 253MA, Hastelloy C-276 / C-22, Monel 400 etc.
Please consult with our technical department for different working conditions and design parameters.
KLINGER Turkey has been offering a wide range of high-quality and engineered expansion joints and metal hoses as well as standard types. Our experienced team focuses on customer satisfaction and quality while providing economical solutions to customer needs.
