Elbow Pressure Balanced Expansion Joints

DN500 elbow pressure balanced expansion joints

KLINGER Turkey designed and manufactured (2) DN500 elbow pressure balanced expansion joints. This type of expansion joints are used where pressure loading on piping or equipment is considered objectionable. Major advantage of pressure balanced design is its ability to absorb externally imposed axial movement without imposing pressure loading on the system Download PDF

3 Hinge System

3 hinged type of expansion joints with angular pre-sets.

KLINGER Turkey delivered 3 hinged type of expansion joints with angular pre-sets. Units are used in a 3 hinge piping system Download PDF

Expansion Joints for District Heating

DN900 hinged type expansion joints

DN900 hinged type expansion joints were designed and manufactured by KLINGER Turkey. Units were designed for 12 barg and delivered to a major city in Europe. Hinged ex- pansion joints are usually used in sets of two or three to absorb lateral and axial deflection in a piping system. Each expansion joint is restricted to […]

Expansion Joints for Cement Plant

lens type and rectangular expansion joints during manufacturing

KLINGER Turkey manufactured several lens type and rectangular expansion joints for a cement plant in Turkey. Expansion joints are manufactured from carbon steel material and sand blasted and painted per customer’s specification against corrosion. Download PDF

DN8000 Lens Type Expansion Joints

DN8000 lens type of expansion joint

KLINGER Turkey manufactured DN8000 lens type of expansion joint. Lens type of expansion joints hold up very good against corrosion and mechanical damages. Drain couplings can be added on convolutions to drain condensate. This type of expansion joints can be manufactured from carbon steel material as well as various grades of stainless steel Download PDF

Expansion Joints for Geothermal Application

Metal expansion joint manufacturing

KLINGER Turkey designed and manufactured several high pressure expansion joints to a geothermal power plant. These expansion joints range from DN300 to DN1950 and include inline pressure balanced, universal tied and single tied expansion joints. DN1200 inline pressure balanced expansion joint is desig- ned for 18 barg and DN750 universal tied expansion joint is designed […]

DN1600 Inline Pressure Balanced Expansion Joints

DN1600 inline pressure balanced expansion joints

KLINGER Turkey designed and manufactured (2)DN1600 inline pressure balanced expansion joints for a major steel plant in Turkey. Inline pressure balanced expansion joints hold pressure forces while allowing axial movements Download PDF

DN1700 Hinged Expansion Joint with 904L Bellows

DN1700 hinged expansion joints with 904L (1.4539) bellows

DN1700 hinged expansion joints with 904L (1.4539) bellows were manufactured from 3 x 0.6mm layers for low spring rates. Addition of copper to 904L gives it corrosion resistant properties superior to the conventional chrome nickel stainless steels, in particular to sulphuric, phosphoric, and acetic acids. This grade is non-magnetic in all conditions and has excellent […]

Big Project for a Power Plant

DN2200 lens type and rectangular type of large expansion joints

18 pieces of DN2200 lens type and 10 pieces of rectangular type of large expansion joints were designed and manufactured by KLINGER Turkey Download PDF

DN2400 Expansion Joints for Steel Industry

DN2400 expansion joints in a 2 gimbal 1 hinge system for a major steel factory

KLINGER Turkey supplied DN2400 expansion joints in a 2 gimbal 1 hinge system for a major steel factory. Bellows and liner is manufactured from Alloy 625 (2.4856) and balance of materials is P265. Alloy 625 has superior resistance to a wide range of corrosive environments of unusual severity. It is an excellent choice for sweater […]
